DELL UltraSharp 24 USB-C Hub Monitor-U2422HE-60.47cm(23.8)

Dell UltraSharp 24 USB-C Hub Monitor

• Designed with wellness in mind: Optimize eye comfort with ComfortView Plus—an always on, built-in low blue light screen that reduces blue light emissions while delivering excellent color.
• Consistent, vibrant colors: Get wide color coverage of 100% sRGB, 100% Rec.709 and 85% DCI-P3.
• In-Plane Switching technology: See consistent color and picture quality across a wide 178/178 degree viewing angle.
• See more details: Experience superb screen clarity with Full HD at 1920x1080 resolution on this 23.8-inch screen.
• Seamless view: Expand your view with virtually borderless InfinityEdge. With a four-sided, ultrathin bezel, you can work with a clear, edge-to-edge display. Use the daisy-chain feature for a seamless multi-monitor setup.
• Boost productivity: Increase your productivity by up to 21% when you use two monitors togetheri. The OSD (Onscreen Menu Display) settings from one monitor can be synchronized across connected monitors for easy multi-monitor setup.

• Connect to productivity: With RJ45 and USB-C®, your monitor serves as a productivity hub that delivers stable Etherneti and up to 90W of power delivery to your laptop.
• Enhance manageability: Simplify your experience with MAC address pass-through, PXE Boot, and Wake-on-LAN conveniently built in.
• Jumpstart productivity: Simply press the monitor power button and the power sync feature seamlessly starts your monitor and connected Dell PC, even when the laptop lid is closed. Compatible with select Dell PCs
• Extensive connectivity: Easily connect to your devices with a wide range of connectivity options including DP, HDMI, super speed USB 10Gbps and USB-C—a single-cable solution that transmits data and video while delivering up to 90W of power for a clutter free desk.
• Fast connections: USB super speed 10Gbps ports enable faster data speed transfers between the PC and peripheral devices connected to the monitor.
• Quick-access front ports: Quick-access USB-C and super speed USB 10Gbps ports located at the front of the monitor enable fast connections to peripherals and mobile device charging with up to 15W of power via USB-C.

• Multitask efficiently: Connect two PC sources to the monitor. Our intelligent Auto KVM feature detects the second connected PC and seamlessly switches controls over. Use the KVM (keyboard, video and mouse) feature to control both PCs with a single keyboard and mouse.

• Style meets function: Crafted with premium platinum silver finish, the U2422HE comes with a small base and an improved cable management design that hides cables in the monitor riser for a clutter free desk space. Navigate and adjust your monitor screen settings with the easy-to-use joystick control.
• Moves with you: Adjust to your comfort with tilt, swivel, pivot and height adjustment to a maximum of 150mm for optimal viewing comfort.

• Environmental standards: This monitor is made of 85% PCR (Post-consumer Recyclable Plastic), meets the latest regulatory and environmental standards such as EnergyStar® and TCO Certified Edge, and is registered EPEAT® Gold.
• Eco-conscious packaging: To reduce our manufacturing impact on the environment, this monitor is shipped Styrofoam-free and the packaging is made of at least 75% recycled cardboard.
• Energy conservation: Save energy when your monitor is not in use with PowerNapi, a feature that dims or puts your monitor to sleep when it’s not in use.
• Advancing sustainability: Dell Technologies is committed to reducing environmental impact throughout the product lifecycle.

• Productive at every level: Easy Arrange allows you to easily tile multiple applications across one or more screens with 38 pre-set window partitions and the ability to personalize up to five windows, giving you improved multitasking abilities.
• Seamless transitions: The auto-restore feature remembers where you left off, so applications will go back to where you left them, even after you’ve unplugged.
• More ways to manage: Asset management reports allow IT managers to quickly capture and track monitor information as well as configure multiple monitors at once through a single setup.
• The key to convenience: Shortcut keys can save you even more time, letting you easily configure your display management settings so you can get to work faster.
• Expanded compatibility: With support for multiple operating systems, Dell Display Manager helps you stay productive however you work.

Diagonal Viewing Size
• 60.47 cm
• 23.8 inches
Preset Display Area (H x V)
• 534.9 mm x 307 mm
• 21.06" x 12.09"
• 164214.3 sq-mm (254.53 sq-inches)
Panel Type
• In-Plane switching Technology
Display Screen Coating
• Anti-glare treatment of the front polarizer (3H) hard coating
Maximum Preset Resolution
• 1920X1080 @ 60Hz
Viewing Angle
• 178° vertical / 178° horizontal
Pixel Pitch
• 0.2745 mm x 0.2745 mm
Pixel Per Inch (PPI)
• 92.5
Contrast Ratio
• 1000 to 1 (typical)
Aspect Ratio
• 16:9
Backlight Technology
• White LED Edgelight System
Brightness
• 250 cd/m2 (typical)
Response Time
• 8 ms for NORMAL mode
• 5 ms for FAST mode

• 1 x Power connector
• 1 x HDMI port
• 1 x DisplayPort
• 1 x USB-C upstream port
• 1 x DisplayPort (out)
• 1 x USB-C upstream port (data only)
• 1 x Super speed USB 10Gbps (USB 3.2 Gen2) Type-A downstream port
• 1 x Audio line-out port
• 1 x RJ45 port
• 1 x Super speed USB 10Gbps (USB 3.2 Gen2) Type-A downstream port with power charging
• 1 x USB-C downstream port (10Gbps, 15W)

• Security lock slot (cable lock sold separately)
• Anti-theft stand lock slot (to panel)

Height with stand (Compressed ~ Extended)
• 364 mm ~ 496 mm
• 14.33" ~ 19.53"
Width
• 537.6 mm
• 21.17"
Depth
• 179.6 mm
• 7.07"
Height without stand
• 310.7 mm
• 12.23"
Width without stand
• 537.6 mm
• 21.17"
Depth without stand
• 48.5 mm
• 1.91"
Weight (panel only - for VESA mount)
• 3.96 kg
• 8.72 lb
Weight (with packaging)
• 8.3 kg
• 18.28 lb

Voltage Required
• 100 VAC to 240 VAC / 50Hz or 60Hz + 3Hz / 2.1A (maximum)
Power Consumption
• 0.3W (Off Mode)
• 0.3W (Standby Mode)
• 11.8W (On Mode)
• 210W (Maximum)
• 14.8W (Pon)
• 50.84kWh (TEC)

Temperature Range
• Operating: 0°C to 40°C (32°F to 104°F)
• Non-operating: –20°C to 60°C (–4°F to 140°F)
Humidity Range
• Operating: 10% to 80% (non-condensing)
• Non-Operating:5% to 90% (non-condensing)
Altitude
• Operating: 5,000 m (16,404 ft) max
• Non-Operating: 12,192 m (40,000 ft) max

• Monitor, Stand Riser, Stand Base
• 1 x Power cable 1X USB Type-C ( C-C) 1M
• 1 X DP Cable (DP to DP) - 1.8 M
• 1 x USB Type -C to Type A - 1 M
• Quick setup guide
• Safety, Environmental, and Regulatory Information
• Factory Calibration Report

Power button sync - Monitor and PC
• Yes - Available on working with select Dell PC's
Adjustability
• Height adjustable (150 mm)
• Tilt (-5° to 21°)
• Swivel (-45° to 45°)
• Pivot (-90° to 90°)"
PbP / PiP
• PbP (No)
• PiP (No)
Daisy Chain Availability
• Yes, with Multi Monitor Sync to synchronize key OSD settings
Dell Display Manager Compatibility
• Yes , Easy Arrange and other key features
Specifications - Service / Support Details
• 3-Year Advanced Exchange Service and Premium Panel Guarantee
Color Support
• Color Gamut
  100% sRGB, 100% REC709, 85% DCI-P3
Color Depth
• 16.7 million colors
Color Calibration Accuracy
• Delta E < 2 (average) for sRGB and Rec 709
Flat Panel Mount Interface
• VESA mounting holes (100 mm x 100 mm-behind attached VESA cover)

Compliant Standards
ENERGY STAR certified Monitor
• EPEAT(Gold) registered where applicable. EPEAT registration varies by country.
• TCO Certified Edge
• RoHS Compliant
• BFR/PVC Free monitor (excluding external cables)
• Meets NFPA 99 leakage current requirements
• Arsenic-Free glass and Mercury-Free for the panel only
